SD™ 10 Series 230 Volt Cord Reel - Single Industrial Receptacle - 25 Meters, 16 Amp - Black

SD™ 10 Series 230 Volt Cord Reel - Single Industrial Receptacle - 25 Meters, 16 Amp - Black

Regular price
$1,232.50
Sale price
$1,232.50
Quantity must be 1 or more




Organize your work space for a safer, more productive work environment. Make Graco your single source for your entire reel bank.



  • 25 meter cord and features a 5 foot lead-in cable.
  • Heavy-duty steel construction, SD Series size 10.
  • Single industrial receptacle
  • Adjustable Arm - Easily change the arm position to fit more applications. Works on walls, ceilings or bench mounts.

  • Heavy-Duty Pedestal - High-strength steel construction with rolled edges and ribbed stress points that won't flex or twist.

UPC Product: 00755652331803
Family Code: FAMCRD
Unit of Measure: EA
Height: 26.5 IN   |  67.31 CM
Length: 21.5 IN   |  54.61 CM
Width: 11 IN   |  27.94 CM
Volume: 3.627 FT3   |  .103 M3
Chargeable Weight: 62 LBS  | 28.12 KG

Technical Specifications

Type Cord Reel
Cord Length (ft) 82
Cord Length (m) 25
Includes Single Industrial Receptacle, Receptáculo industrial único
Insulation Type H07RN-F, H07RN-F
Maximum Current (A) 16
Maximum Operating Temperature (°C) 50
Maximum Operating Temperature (°F) 122
Overall Height (cm) 49.53
Overall Height (in) 19.5
Overall Height (mm) 495.3
Overall Length (cm) 44.5
Overall Length (in) 17.5
Overall Length (mm) 445
Overall Width (cm) 11.938
Overall Width (in) 4.7
Overall Width (mm) 119.38
Power Cord Connect Type CEE 7/7 16 A
Reel Color Black, Negro
Series 10
Sound Power Level (dB(A)) 87
Sound Pressure Level (dB) 80
Voltage (V ac) 230
Weight (kg) 24.54
Weight (lb) 54.1
Wire Gauge Size (mm²) 2,5
Model SD
