Used for sealant and adhesive materials
Feel free to call or chat with us for recommendations.
📦
Ships in 6-10 days, shipping times may vary
🚚
Free Shipping on orders $500 and up., some items have a optional lift gate for a additional fee
Flat rate of $12.50 for orders below $500.
Click here for more info.
Flat rate of $12.50 for orders below $500.
Click here for more info.
🔁
30-day returns. Click here for more info.
UPC Product: 00633955697065
Family Code: FAMAPA
Unit of Measure: EA
Height:
9.6 IN
| 24.384 CM
Length:
8.1 IN
| 20.574 CM
Width:
5 IN
| 12.7 CM
Volume:
.225 FT3
| .006 M3
Chargeable Weight:
3.89 LBS
| 1.76 KG
Technical Specifications
| Air Inlet Size (cm) | 0.3175 |
|---|---|
| Air Inlet Size (in) | 1/8 |
| Air Inlet Size (mm) | 3.175 |
| Air Inlet Thread Gender | Female |
| Air Inlet Thread Type | NPT |
| Compatible Material | Sealants, Adhesives |
| Fluid Inlet Size (cm) | 1.27 |
| Fluid Inlet Size (in) | 1/2 |
| Fluid Inlet Size (mm) | 12.7 |
| Fluid Inlet Thread Gender | Female |
| Fluid Inlet Thread Type | NPT |
| Fluid Outlet Size (cm) | 1.5875 |
| Fluid Outlet Size (in) | 5/8-18 |
| Fluid Outlet Size (mm) | 15.875 |
| Fluid Outlet Thread Gender | Male |
| Fluid Outlet Thread Type | UNF |
| Maximum Working Pressure (bar) | 345 |
| Maximum Working Pressure (kPa) | 34500 |
| Maximum Working Pressure (psi) | 5000 |
| Type | Dispense Valve |
| Component Type | Single Component |
| Ambient/Warm Melt/Hot Melt | Ambient;Warm Melt |
| Gun Activation | Automatic |
| Application | Bonding, Sealing, Gasketing |
| Maximum Working Pressure (MPa) | 34.5 |
| Orifice Diameter (in) | 0.125 |
| Outlet Size (in) | 5/8-18 |
| Outlet Size (cm) | 1.5875 |
| Model | Endure |
