Graco Modu-Flo® HLJ-5 Hydraulic Pump

Graco Modu-Flo® HLJ-5 Hydraulic Pump

Regular price
$937.00
Sale price
$937.00
Quantity must be 1 or more


The Modu-Flo system is ideal for applications where minimizing downtime is critical. Customizing is easy–just mix and match pumps, reservoir and manifolds in any configuration to meet any application. Replace the pump or reservoir without disconnecting lubrication lines.

  • Modular system design allows configurations to work in all applications
  • Easy to standardize on components and reduce inventory
  • Adjustable pump output for fast, convenient customization
  • Lubriquip part number 521-000-011
UPC Product: 633955351066
Family Code: FAMMPM
Unit of Measure: EA
Height: 3.1 IN   |  7.874 CM
Length: 11.5 IN   |  29.21 CM
Width: 3.1 IN   |  7.874 CM
Volume: .064 FT3   |  .002 M3
Chargeable Weight: 4.34 LBS  | 1.97 KG

Technical Specifications

Type Hydraulic Piston Pump
Application In-Plant Machinery
Compatible Material Oil, Grease
Maximum Cycle Rate (CPM) 60
Maximum Fluid Output Pressure (psi) 2000
Maximum NLGI Grade #2
Maximum Working Pressure (bar) 207
Maximum Working Pressure (kPa) 20680
Maximum Working Pressure (psi) 3000
Model Modu-Flo
Power Type Hydraulic
Series HLJ-5
Compatible Metering Device Series Progressive
Maximum Working Pressure (MPa) 45.5
maximum_fluid_output_pressure_bar 138
