G3000 Gear Flow Meter, positive displacement, 0.02 to 1.0 gpm (75 to 3800 cc/min), low to medium viscosity materials
Feel free to call or chat us for recommendations.
Estimated to ships in 6 to 10 business days. Need it sooner? Call us for expedited shipping quote.
- Designed for non-abrasive and unfilled materials
- Highly accurate, even with low flow rates
- Stainless steel components can handle low to medium viscosity materials
UPC Product: 00633955326552
Family Code: FAMPCM
Unit of Measure: EA
Height:
4.8 IN
| 12.192 CM
Length:
6 IN
| 15.24 CM
Width:
6 IN
| 15.24 CM
Volume:
.1 FT3
| .003 M3
Chargeable Weight:
4.6 LBS
| 2.09 KG
Technical Specifications
| Inlet Size (cm) | 0.635 |
|---|---|
| Inlet Size (in) | 1/4 |
| Inlet Size (mm) | 6.35 |
| Inlet Thread Gender | Female |
| Inlet Thread Type | NPT |
| Maximum Flow Rate (cc/min) | 3800 |
| Maximum Flow Rate (GPM) | 1 |
| Maximum Viscosity (cP) | 3000 |
| Minimum Flow Rate (cc/min) | 75 |
| Minimum Flow Rate (GPM) | 0.02 |
| Minimum Viscosity (cP) | 20 |
| Overall Height (cm) | 10.2 |
| Overall Height (in) | 4 |
| Overall Height (mm) | 101.6 |
| Accuracy (%) | +/- 0.5 |
| Maximum Ambient Temperature (°F) | 140 |
| Maximum Fluid Temperature (°F) | 180 |
| Maximum Fluid Temperature (°C) | 82 |
| Maximum Voltage (V dc) | 30 |
| Maximum Working Pressure (MPa) | 27.6 |
| Maximum Working Pressure (psi) | 4000 |
| Maximum Working Pressure (kPa) | 27600 |
| Maximum Working Pressure (bar) | 276 |
| Minimum Voltage (V dc) | 10 |
| Outlet Size (cm) | 0.635 |
| Outlet Size (in) | 1/4 |
| Outlet Size (mm) | 6.35 |
| Outlet Thread Gender | Female |
| Outlet Thread Type | NPT |
| Overall Width (cm) | 7.44 |
| Overall Width (in) | 2.97 |
| Overall Width (mm) | 74.4 |
| Weight (lb) | 6 |
| Wetted Parts | 303 Stainless Steel, Tungsten Carbide, PTFE |
