Graco SDL6DA SDXâ„¢  20, Air/Water/Antifreeze/WWS, 1/2 in (13 mm) Inlet, Bare Reel (1/2 in X 50 ft (13 mm X 15 m) Capacity), NPT, Overhead Mount, White

Graco SDL6DA SDXâ„¢ 20, Air/Water/Antifreeze/WWS, 1/2 in (13 mm) Inlet, Bare Reel (1/2 in X 50 ft (13 mm X 15 m) Capacity), NPT, Overhead Mount, White

Regular price
$863.00
Sale price
$863.00
Quantity must be 1 or more


Choose Graco’s flagship SDX hose reels for high-quality performance and versatility. Built using specially crafted components, including a rigid metal frame and low-friction swivels, it’s available in five colors

With its durable metal spool and rigid pedestal frame, the compact SDX Series is ideal for indoor and limited outdoor use in car dealerships, fleet maintenance, public works garages and light-utility service trucks.

  • Includes a stainless-steel swivel shaft for extended service life when transporting air, water, antifreeze, windshield wash solvent and other fluids.
  • Low-Friction Cartridge Swivel - Provides smooth reel performance with an easy-to-replace swivel cartridge, simplifying repairs.
  • Full-Flow Swivel - Maximize material flow with minimal pressure drop for faster fills to get more vehicles through your shop
  • Adjustable Arm - Easily change the arm position for your application
  • Large Hose Capacity with Small Profile - Compact pedestal and spool fits into tight spaces and can accommodate 35-65 foot (10.7-19.8 meters) hose (NPT air/water) capacity for a wide variety of applications
  • Durable Finish - Baked-on enamel finish protects reel from corrosion
UPC Product: 00769946206555
Family Code: FAMSDR
Unit of Measure: EA
Height: 0 IN   |  0 CM
Length: 0 IN   |  0 CM
Width: 0 IN   |  0 CM
Volume: 0 FT3   |  0 M3
Chargeable Weight: 0 LBS  | 0 KG

Technical Specifications

Color White
Hose Inside Diameter (in) 3/8
Hose Inside Diameter (mm) 9.525
Hose Length (ft) 50
Hose Length (m) 15
Inlet Size (in) 1/2
Inlet Size (mm) 12.7
Inlet Thread Type NPSM
Maximum Temperature (°C) 87
Maximum Temperature (°F) 190
Maximum Working Pressure (psi) 300
Minimum Temperature (°C) -28
Minimum Temperature (°F) -20
Mount Location Overhead Mount
Outlet Size (in) 3/8
Outlet Size (mm) 9.525
Outlet Thread Type NPT
Overall Height (in) 19.5
Overall Height (mm) 498
Overall Length (in) 17.1
Overall Length (mm) 435
Overall Width (in) 7
Overall Width (mm) 177
Series 10
Wetted Parts Stainless Steel, Anodized Aluminum, Nitrile Rubber
Application Air, Water, Antifreeze, WWS
Type Spring-Rewind Reel
Recommended Environment Indoor, Limited Outdoor
Frame Type Single Pedestal
Bare Reel 1
Reel Thread Type NPT
Inlet Thread Gender Female
Outlet Thread Gender Male
Recommended Fluid Type Air, Water, Antifreeze, WWS
Hose Reel Type Bare Reel
Model SDX
includes_hose No
