Maintain consistent agitator speed, even with an empty drum
Feel free to call or chat with us for recommendations.
📦
Ships in 6-10 days, shipping times may vary
🚚
Free Shipping on orders $500 and up., some items have a optional lift gate for a additional fee
Flat rate of $12.50 for orders below $500.
Click here for more info.
Flat rate of $12.50 for orders below $500.
Click here for more info.
🔁
30-day returns. Click here for more info.
- Quick install, requires less than 1 minute to setup
- Prevents over agitation for shear sensitive and waterborne materials
- Saves energy by limiting agitator over speeding
- Prevents motor over speeding, extending lifetime
- Maintains constant set speed even as viscosity or drum levels change
- Provides closed-loop speed control for agitators
UPC Product: 00633955112605
Family Code: FAMQFP
Unit of Measure: EA
Height:
5 IN
| 12.7 CM
Length:
8.4 IN
| 21.336 CM
Width:
9.6 IN
| 24.384 CM
Volume:
.233 FT3
| .007 M3
Chargeable Weight:
2.429 LBS
| 1.102 KG
Technical Specifications
| Air Inlet Size (cm) | 0.3175 |
|---|---|
| Air Inlet Size (in) | 1/8 |
| Air Inlet Size (mm) | 3.175 |
| Air Inlet Thread Type | NPT |
| For Use With | Air Drive Agitators |
| Maximum Air Inlet Pressure (bar) | 7 |
| Maximum Air Inlet Pressure (kPa) | 700 |
| Maximum Air Inlet Pressure (psi) | 100 |
| Maximum Speed (RPM) | 1000 |
| Minimum Air Inlet Pressure (bar) | 4.9 |
| Minimum Air Inlet Pressure (kPa) | 490 |
| Minimum Air Inlet Pressure (psi) | 70 |
| Minimum Speed (RPM) | 100 |
| Outside Diameter (cm) | 102 |
| Outside Diameter (in) | 4 |
| Outside Diameter (mm) | 10.2 |
| Overall Height (cm) | 11.4 |
| Overall Height (in) | 4.5 |
| Overall Height (mm) | 11.4 |
| Weight (kg) | 0.64 |
| Weight (lb) | 1.4 |
