Graco HP-50 Lubricator with 4 Pumps

Graco HP-50 Lubricator with 4 Pumps

Regular price
$47,000.00
Sale price
$47,000.00
Quantity must be 1 or more


Single plunger force feed design is highly efficient for injecting lubricants and/or compatible fluids into high pressure systems. Vacuum sight feeds on self-contained pumping units show output of lubricant to individual lubrication points.

For lubricating compressor and circulator cylinder walls, heavily loaded bearings and other moving parts.

  • Operating pressures up to 60,000 psi (4137 bar)
  • All working parts are totally enclosed and self-lubricated
  • Individual pumping units easily removed for service
  • Feed rate infinitely variable from minimum to maximum with simple hand adjustment
  • Lubriquip part number 250-000-269

UPC Product: 00633955349193
Family Code: FAMMAN
Unit of Measure: EA
Height: 60.96 CM   |  24 IN
Length: 18 IN   |  45.72 CM
Width: 31.2 IN   |  79.248 CM
Volume: 7.8 FT3   |  .221 M3
Chargeable Weight: 94.35 KG  | 208 LBS

Technical Specifications

Type Box Lubricator
Compatible Material Oil
Maximum Drive Speed (RPM) 36
Maximum Fluid Viscosity (SUS) 5000
Maximum Number of Drops Per Stroke (drops/stroke) 4
Maximum Operating Temperature (°C) 49
Maximum Operating Temperature (°F) 120
Maximum Reservoir Capacity (gal) 2.25
Maximum Reservoir Capacity (L) 8.5
Maximum Reservoir Capacity (pt) 18
Maximum Reservoir Capacity (qt) 9
Maximum Working Pressure (bar) 3447
Maximum Working Pressure (kPa) 344700
Maximum Working Pressure (psi) 50000
Minimum Drive Speed (RPM) 3
Minimum Fluid Viscosity (SUS) 100
Minimum Number of Drops Per Stroke (drops/stroke) 1
Minimum Operating Temperature (°C) -29
Minimum Operating Temperature (°F) -20
Overall Depth (cm) 57.61
Overall Depth (in) 22.68
Overall Depth (mm) 576.1
Overall Height (cm) 37.5
Overall Height (in) 14.77
Overall Height (mm) 375
Overall Width (cm) 29.36
Overall Width (in) 11.56
Overall Width (mm) 293.6
Pump Size (cm) 0.6
Pump Size (in) 1/4
Pump Size (mm) 6.3
Reservoir Material Cast Iron
Series HP-50
Model Manzel

;
