HG 6000 Flow Meter Kit for Ratio Monitoring

HG 6000 Flow Meter Kit for Ratio Monitoring

Regular price
$7,080.00
Sale price
$7,080.00
Quantity must be 1 or more


KIT INCLUDES: METER, HELI GEAR, AMB W/SENSOR [QTY. 1 ]; SWIVEL, SST, 1/2 NPT [QTY. 1 ]; FITTING, NIPPLE [QTY. 1 ]; FITTING, BUSHING, PIPE [QTY. 1 ]; CABLE, 5PIN, MALE/FEMALE, 4.0 M [QTY. 1 ]

UPC Product: 00755652065630
Family Code: FAMOMA
Unit of Measure: EA
Height: 8 IN   |  20.32 CM
Length: 16 IN   |  40.64 CM
Width: 12 IN   |  30.48 CM
Volume: .889 FT3   |  .025 M3
Chargeable Weight: 15 LBS  | 6.8 KG

Technical Specifications

Compatible Material Solventborne and Waterborne Paints and Resins, Oil and Catalysts
For Use With HFR Fixed-Ratio Proportioner
Inlet Size (in) 3/4
Inlet Thread Gender Female
Inlet Thread Type NPT
Maximum Flow Rate (cc/min) 22700
Maximum Fluid Pressure (bar) 420
Maximum Fluid Pressure (kPa) 42000
Maximum Fluid Pressure (psi) 6000
Maximum Viscosity (cP) 1000000
Minimum Flow Rate (cc/min) 50
Minimum Viscosity (cP) 30
Overall Height (cm) 14.2
Overall Height (in) 5.6
Overall Height (mm) 142
Overall Length (cm) 15
Overall Length (in) 6.1
Overall Length (mm) 155
Series HG6000
Type Helical Gear Flow Meter Kit
