High volume air pressure regulator, 3/4 in NPT inlet and outlet, 380 cfm, 125 psi max

High volume air pressure regulator, 3/4 in NPT inlet and outlet, 380 cfm, 125 psi max

Regular price
$255.50
Sale price
$255.50
Quantity must be 1 or more


UPC Product: 00633955328822
Family Code: FAMQFP
Unit of Measure: EA
Height: 6 IN   |  15.24 CM
Length: 12 IN   |  30.48 CM
Width: 6 IN   |  15.24 CM
Volume: .25 FT3   |  .007 M3
Chargeable Weight: 6 LBS  | 2.72 KG

Technical Specifications

Air Inlet Size (cm) 1.905
Air Inlet Size (in) 3/4
Air Inlet Size (mm) 19.05
Air Inlet Thread Type NPT
For Use With King, King
Gauge Port Size (cm) 0.635
Gauge Port Size (in) 1/4
Gauge Port Size (mm) 6.35
Gauge Port Type NPT
Handle Type Tee
Includes Regulator Only, Solo regulador
Maximum Air Flow Rate (SCFM) 380
Maximum Air Inlet Pressure (bar) 21
Maximum Air Inlet Pressure (kPa) 2100
Maximum Air Inlet Pressure (psi) 300
Maximum Operating Temperature (°C) 49
Maximum Operating Temperature (°F) 120
Maximum Regulated Pressure (bar) 8.6
Maximum Regulated Pressure (kPa) 860
Maximum Regulated Pressure (psi) 125
Minimum Operating Temperature (°C) 4
Minimum Operating Temperature (°F) 40
Minimum Regulated Pressure (bar) 0
Minimum Regulated Pressure (kPa) 0
Minimum Regulated Pressure (psi) 0
Type Air Regulator
Maximum Air Inlet Pressure (MPa) 2.1
Maximum Regulated Pressure (MPa) 0.86
Air Outlet Size (cm) 1.905
Air Outlet Size (in) 3/4
Air Outlet Size (mm) 19.05
Air Outlet Thread Type NPT
