High-volume regulator

High-volume regulator

Regular price
$8,193.07
Sale price
$8,193.07
Quantity must be 1 or more


Fluid regulators keep your system functioning more productively. For a balanced fluid system, pressure control is essential. Graco provides a wide selection of fluid pressure regulators and back pressure valves. Together, these controls keep your system functioning more productively by providing rugged, precise pressure regulation.

UPC Product: 00633955568440
Family Code: FAMCNV
Unit of Measure: EA
Height: 13.2 IN   |  33.528 CM
Length: 14.4 IN   |  36.576 CM
Width: 13.2 IN   |  33.528 CM
Volume: 1.452 FT3   |  .041 M3
Chargeable Weight: 38 LBS  | 17.24 KG

Technical Specifications

Actuation Type Air
Gauge Port Size (cm) 0.635
Gauge Port Size (in) 1/4
Gauge Port Size (mm) 6.35
Gauge Port Type NPT
Includes Gauge, Medidor
Inlet Size (cm) 3.81
Inlet Size (in) 1-1/2
Inlet Size (mm) 38.1
Inlet Thread Type NPT
Maximum Flow Rate (GPM) 20
Maximum Flow Rate (L/min) 75.71
Maximum Regulated Pressure (bar) 18
Maximum Regulated Pressure (kPa) 180
Maximum Regulated Pressure (psi) 260
Maximum Viscosity (cP) 500
Maximum Working Pressure (bar) 21
Maximum Working Pressure (kPa) 2100
Maximum Working Pressure (psi) 300
Minimum Regulated Pressure (bar) 0
Minimum Regulated Pressure (kPa) 0
Minimum Regulated Pressure (psi) 0
Outlet Size (cm) 3.81
Outlet Size (in) 1-1/2
Outlet Size (mm) 38.1
Wetted Material Carbide, PTFE, Stainless Steel
Type Fluid Regulator
Maximum Fluid Pressure (bar) 21
Maximum Fluid Pressure (kPa) 2100
Maximum Fluid Pressure (psi) 300
Maximum Fluid Pressure (MPa) 2.1
Maximum Regulated Pressure (MPa) 1.8
Maximum Working Pressure (MPa) 2.1
Minimum Regulated Pressure (MPa) 0
