Graco 17L324 Water Pressure Regulator

Graco 17L324 Water Pressure Regulator

Regular price
$946.00
Sale price
$946.00
Quantity must be 1 or more


17L324 1500 PSI @ 7.0 GPM  3/8 npt(f) Inlet/Outlet Size &  5 mm Seat Size

Series A P20-VM npt  Mechanical, fluid pressure 1500 psi Maximum Fluid Inlet Pressure &  15-290 psi Regulated Pressure Range.

Model 17L324  is mechanically operated fluid pressure regulators designed primarily for use with low to medium viscosity fluids.

A fluid pressure regulator is used in air spray systems to ensure accurate, positive control of fluid pressure to an air spray gun or to a low pressure dispensing valve or atomizing head.

A regulator installed at a circulating line take-off or pump reduces main line pressure to maintain the desired fluid pressure to the air spray gun or to a low pressure dispensing valve or atomizing head.

**Torque to 2 N•m (18 in-lb). For 17L324, torque to 5.6 N•m (50 in-lb).

Parts:

HOUSING, lower 1
24Z180 SEAT, valve 1
15Y036 O-RING 1
15Y035 O-RING 2
17L570 BALL, 6mm, tungsten carbide, 1
15A205 SUPPORT, ball 1
117090 SPRING, compression 1
15A144 COVER 1
17R503 COVER, for 17L324 only 1
117123 SCREW, fhms, M4x10 2
117099 PLUG, threaded, 2
117085 SEAL, ring 1
117099 PLUG, threaded 1
245372 PLUNGER, valve 1
15A179 DIAPHRAGM 1
15A172 CAP, spring 1
117122 NUT, seal-lock 1
117095 SPRING, compression 1
15A177 PLATE, spring, top 1
117105 BALL, 6 mm 1
15A185 PACKING, PTFE with carbon 1
245365 HOUSING, upper 1
117126 SCREW, shcs, M5x16 8
15A241 SCREW, custom 1
