The Delco® CWE Portable Series DWM3540041B (part 65455) is an electric, cold water, wall mount pressure washer rated at 3500 PSI and 4.0 GPM, for 14,000 cleaning units. A 10HP, 230V, single-phase, 38A motor belt-drives a UDOR® industrial triplex pump. The unit is built on a large powder-coated steel wall mount frame. It suits wash bays, shops and other fixed locations that need a steady electric cold water washer.
Performance & Operation
- 3500 PSI at 4.0 GPM (14,000 cleaning units)
- 10HP / 230V / 1-phase / 38A electric motor
- High-temperature water feed, capable up to 165° F
- Automatic start/stop feature
- Built-in hour meter
UDOR® Industrial Triplex Pump
- Belt-driven, slow-speed industrial triplex pump
- Forged brass manifold
- Ceramic-coated plunger sleeves
- Thermal relief valve
- External unloader with bypass hose
Frame & Construction
- Large wall mount steel frame
- Powder-coated steel frame for corrosion resistance
- Steel powder-coated panel cover
- Dimensions: L 33" x W 22" x H 18"
- Weight: 350 lbs.
Included Equipment
- 3/8" x 50' steel-braided Armor Hose®
- Quick-connect nozzles: 15°, 25°, 40° and soap
- Lance and trigger gun
- Downstream injector
Warranty
- 10-year frame
- 5-year pump
- 1-year motor
Optional large-frame accessories include the Remote Box (80655) and Wall Mount Kit (80653). If you have questions about the Delco DWM3540041B or need help choosing a washer, call Pittsburgh Spray Equipment at 888-714-1410.
Specifications
| Model | DWM3540041B |
| Part Number | 65455 |
| Series | CWE Portable (Wall Mount) |
| Pressure | 3500 PSI |
| Flow | 4.0 GPM |
| Cleaning Units | 14,000 |
| Motor | 10HP / 230V / 1-phase / 38A |
| Pump | UDOR® industrial triplex |
| Drive | Belt |
| Water | Cold water (feed up to 165° F) |
| Frame | Large Wall Mount / Steel |
| Hose | 3/8" x 50' steel-braided Armor Hose® |
| Weight | 350 lbs |
| Dimensions | L 33" x W 22" x H 18" |
| Warranty | 10-Year Frame, 5-Year Pump, 1-Year Motor |
