Standard Features

PUMP

Industrial Duty General triplex plunger pump with oil bath crankcase, stainless valves and all brass manifolds, most pumps are belt driven although we do offer flange and coupling driven pumps as well

MOTOR

Heavy Duty full 1.25 service factor TEFC 1750 rpm overload protected high efficiency electric motors

OTHER

Liquid filled pressure gauge, Fully adjustable pressure regulator and chemical injector, thermo pump protection, 50 ft hose, gun and wand with five nozzles

HEATER

316 stainless steel heat exchanger coil, designed for continuous use, large 70 gallon (single coil models) and 120 gallon (dual coil models) heater storage tanks – allows for continuous recovery even when trigger gun (s) not in use, no open flame, can be installed in virtually any location, compact foot print, stand and explosion proof models, no venting required, heater exchanger coils do not require decalcification, require less KW than input direct-immersion type electrically heated models, low heat exchanger solution cut-off switch, adjustable temperature controller, pin- type Calrod heating elements with incoloy sleeves.

OPTIONS

Full range of portable frames, stainless steel covers and heater skins, 50hz models, ASME B31.1, 2004 (power piping) code compliant models available and Explosion Proof Units.

FRAME

Heater and pumps base is made of heavy gauge steel and is painted with powder coated process

Note: Product doesn't come with a battery.
