Details
FEATURES:
• Safety
• Patented Fused Brake Design- Proven durability that increases safety with a lifetime replacement warranty
• Overload Protection- Slip clutch design increases safety by preventing lifting or pulling damaging loads
• Weston Style Dual Pawl Brake System- Double pawl design increases safety
• Alloy Steel Hooks- Industrial rated hooks rotate 360 degrees for easy rigging. Hooks slowly stretch to indicate an overload situation increasing jobsite safety
• Durability
• Sealed Ball Bearing Design- Increases efficiency and promotes smooth operation
• Cast Steel Safety Latches- Increased durability with heavy duty safety latches secured with Allen screws and lock nuts
• Heat Treated Load Plates- Heat treated, case hardened and corrosive resistant coated internal parts extend the life of the hoist in the harshest of environments
• Grade 100 Load Chain- Corrosive resistant grade 100 load chain is stronger than grade 80 load chain extending the life of the hoist
SPECIFICATIONS:
• Hand Chain Overhaul (Ft.) to Lift Load 1Ft.: 396
• Overload Protection: Yes
• Hand Chain Pull Force (LBF) to Move Load: 79
• Headroom (In.): 29-7/8
• Lift (Ft.): 10
• Number of Falls: 4
• Load Capacity (Tons): 10
• Load Chain Dimensions (Mm.): 9 x 27
• Weight (Lbs.): 174
• Safety
• Patented Fused Brake Design- Proven durability that increases safety with a lifetime replacement warranty
• Overload Protection- Slip clutch design increases safety by preventing lifting or pulling damaging loads
• Weston Style Dual Pawl Brake System- Double pawl design increases safety
• Alloy Steel Hooks- Industrial rated hooks rotate 360 degrees for easy rigging. Hooks slowly stretch to indicate an overload situation increasing jobsite safety
• Durability
• Sealed Ball Bearing Design- Increases efficiency and promotes smooth operation
• Cast Steel Safety Latches- Increased durability with heavy duty safety latches secured with Allen screws and lock nuts
• Heat Treated Load Plates- Heat treated, case hardened and corrosive resistant coated internal parts extend the life of the hoist in the harshest of environments
• Grade 100 Load Chain- Corrosive resistant grade 100 load chain is stronger than grade 80 load chain extending the life of the hoist
SPECIFICATIONS:
• Hand Chain Overhaul (Ft.) to Lift Load 1Ft.: 396
• Overload Protection: Yes
• Hand Chain Pull Force (LBF) to Move Load: 79
• Headroom (In.): 29-7/8
• Lift (Ft.): 10
• Number of Falls: 4
• Load Capacity (Tons): 10
• Load Chain Dimensions (Mm.): 9 x 27
• Weight (Lbs.): 174
