Product Overview

Katool USA Full Rise Scissor Lift KT‑X95 is a flush-mount full rise scissor lift engineered to deliver powerful lifting performance and reliable operation for automotive maintenance, diagnostics, and repairs. With an 8,000 lb (3,500 kg) capacity and a full height rise of 72.3 in, this lift gives technicians comfortable access to the vehicle underbody while preserving workspace when lowered. CE certified and tested beyond industry standards, it’s built to perform in professional environments.

Whether you’re servicing cars, SUVs, or light trucks, the KT-X95 combines robust construction with advanced safety systems — including pneumatic lock release, 24 V control system, and height limit protections — making it a great choice for busy shops and serious DIYers.

 Key Features

  • 8,000 lb (3,500 kg) max lifting capacity — handles most cars, SUVs, and light trucks with ease.

  • 72.3″ full rise height — gives excellent undercarriage access for detailed work.

  • Flush-mount design — minimizes trip hazards and preserves workspace when not in use.

  • Pneumatic safety lock release — reliable locking with compressed air control.

  • 24 V safe control system & height limit switch — enhanced operator safety.

  • Composite rubber lifting blocks included — secure contact points protect vehicle surfaces.

  • Drive-up ramp lock design — extended runways for longer wheelbases.

  • Aluminum motor with cooling fan — prevents overheating during extended cycles.

  • Self-lubricating bushings and bearings — smoother operation and lower maintenance.

  • CE Certified — tested to 115 % dynamic and 150 % static load standards.



Specification Details
Model KT-X95
Lifting Capacity 8,000 lbs (3,500 kg)
Max Lifting Height 72.3 in (1,836 mm)
Lifting Time ≤ 50 seconds
Platform Length 58.9 in (1,496 mm)
Platform Width 24.4 in (620 mm)
Motor Power 2.2 kW
Rated Oil Pressure 20 MPa
Air Pressure Requirement 6–8 kgf/cm² (approximately 85–115 psi)
Control Voltage 24 V safe control
Safety Features Height limit switch; pneumatic lock system
Design Flush-mount design with drive-up ramps and locking mechanism
Certifications CE certified; tested to 115% dynamic load and 150% static load
Equipment Included Lifting blocks; control system
Installation Requirements No concrete anchoring required
