Stainless steel construction
Quickly change between guns, regulators, and lines to reduce setup, changeover, and maintenance time
Don’t flush through guns tips, disconnect and flush through quick connects. Reduce flushing time and avoid premature tip wear.
Provide flexibility for operators, especially those that own or maintain their own guns. Promote daily maintenance.
Compatible with Graco Gun Regulators and Restrictors
Quick couplers automatically seal once disconnected
UPC Product: 00633955236615
Family Code: FAMCNV
Unit of Measure: EA
Height:
.85 IN
| 2.159 CM
Length:
2 IN
| 5.08 CM
Width:
2.9 IN
| 7.366 CM
Volume:
.003 FT3
| 0 M3
Chargeable Weight:
.1 LBS
| .04 KG
Technical Specifications
| Connection Type | Threaded, Twist Lock |
|---|---|
| For Use With | Hose, Manguera |
| Inlet Thread Gender | Male |
| Material | Stainless Steel |
| Maximum Working Pressure (bar) | 21 |
| Maximum Working Pressure (kPa) | 2100 |
| Maximum Working Pressure (psi) | 300 |
| Outlet Thread Gender | Female |
| Outlet Thread Type | NPSM |
| System of Measurement | Imperial |
| Type | Coupling |
| Maximum Working Pressure (MPa) | 2.1 |
| Outlet Size (in) | 3/8 |
| Outlet Size (mm) | 9.525 |
| Outlet Size (cm) | 0.9525 |
