Delco Patriot DPT3080141EAC11 3000 PSI @ 8.0 GPM CRX® 750 UDOR® Triplex Belt Drive Gas Hot Water Pressure Washer, Oil-Fired

The Delco Patriot DPT3080141EAC11 (part 65367) is a gas-engine hot water pressure washer. It delivers 3000 PSI at 8.0 GPM for 24,000 cleaning units. Power comes from a key-start CRX® 750 (750cc) V-twin engine that belt-drives a UDOR® industrial triplex pump. The 120V oil-fired burner runs on No. 1/No. 2 diesel or kerosene. The Patriot is built for versatility and works as a portable or stationary unit. Extended 15-gallon gas and 15-gallon diesel tanks make it a fit for contractors and fleet, equipment and facility cleaning crews that need sustained hot water output. Not for sale in California.

Engine & Burner

• CRX® 750 V-twin horizontal engine with key-start (battery not included)
• Low oil shutdown
• 120V burner system with corrosion-resistant stainless steel coil cover
• 1/2" Schedule 80 horizontal coil
• Burner fuels: No. 1/No. 2 diesel or kerosene
• 3.4 kW generator with one 120V duplex outlet
• NEMA 4X electrical enclosure with burner on/off rocker switch and hour meter

Pump

• UDOR® industrial triplex pump, belt drive
• 1750 RPM slow speed
• Forged brass manifold
• Ceramic-coated plunger sleeves
• Thermal relief valve
• External unloader with bypass hose
• Isolated pump and engine plate with vibration dampeners

Frame

• Heavy-duty 1-1/2" round tubular steel design
• Powder-coated for corrosion resistance
• Removable feet for forklift capability and alternative mounting options
• 15 gal. gas tank and 15 gal. diesel tank

Included

• 3/8" x 50' steel-braided Armor Hose®
• Trigger gun and lance
• Quick-connect nozzles: 15°, 25° and 40°
• Engine oil 10W-30

Warranty & Optional Accessories

• 10-Year Frame, 5-Year Pump, 3-Year Engine
• Optional Analog Thermostat Kit (80657)
• Optional Steam Kit (80664)

Have questions about the Delco Patriot or need help choosing the right hot water unit? Call Pittsburgh Spray Equipment at 888-714-1410.

Specifications
