The Delco Streamliner DSL4040142EDC11 (FNA part 65363) is a gas-engine hot water pressure washer rated at 4000 PSI and 4.0 GPM for 16,000 cleaning units. It pairs a CRX® 420cc key-start engine with a direct-drive UDOR® industrial triplex pump and an oil-fired 120V burner that runs on No. 1/No. 2 diesel or kerosene. It is compact enough to fit in a transit van or truck bed and pass through a 36" doorway, which suits mobile operators who need hot water cleaning on the go. Not for sale in California.
Engine, Burner & Generator
- CRX® 420cc key-start engine (battery not included) with low-oil shutdown
- 1750 RPM slow-speed operation
- 120V burner system with burner on/off rocker switch and hour meter
- 3.4 kW generator with two 120V outlets
- 1/2" schedule 80 horizontal coil and high-temperature safety switch
- Large-capacity fuel tanks: 5.0 gal gas and 10.0 gal diesel
UDOR® Industrial Triplex Pump
- Direct drive
- Forged brass manifold
- Ceramic-coated plunger sleeves
- Thermal relief valve
- External unloader with bypass hose
- Isolated pump and engine plate with vibration dampeners
Frame & Mobility
- Heavy-duty 1-1/2" round tubular steel frame
- Powder-coated for corrosion resistance
- Wheel brake system
- Dimensions: L 50" x W 32" x H 47". Weight: 450 lbs
What's Included
- 3/8" x 50' steel-braided Armor Hose®
- Trigger gun and lance
- Quick-connect nozzles: 15°, 25°, and 40°
- Downstream injector
- Engine oil 10W-30
Warranty & Optional Accessories
- Warranty: 10-Year Frame, 5-Year Pump, 3-Year Engine
- Optional Analog Thermostat Kit (part 80657)
- Optional Steam Kit (part 80646)
Questions about the Delco Streamliner DSL4040142EDC11 or need help choosing the right hot water unit? Call Pittsburgh Spray Equipment at 888-714-1410.
Specifications
| Model | DSL4040142EDC11 |
| Part Number | 65363 |
| Pressure | 4000 PSI |
| Flow | 4.0 GPM |
| Cleaning Units | 16,000 |
| Engine | CRX® 420cc key-start (battery not included) |
| Pump | UDOR® industrial triplex |
| Drive | Direct |
| Burner Fuel | No. 1/No. 2 diesel or kerosene (oil-fired) |
| Burner Voltage | 120V |
| Generator | 3.4 kW, two 120V outlets |
| Gas Tank | 5.0 gal |
| Diesel Tank | 10.0 gal |
| Hose | 3/8" x 50' steel-braided Armor Hose® |
| Weight | 450 lbs |
| Dimensions | L 50" x W 32" x H 47" |
