Graco 24A537 Small Air Valve Mech Kit

Graco 24A537 Small Air Valve Mech Kit

$165.00
$165.00
Quantity must be 1 or more

Related Manuals:

  • 406747C, Air Valve Repair Kits, Instructions-Parts, English — View PDF
  • 3A5023A, Stainless Steel 15:1 Pump Repair, Parts (English) — View PDF
  • 3A5266G, Manual, Grease or Oil A4000 Reciprocating Lube-Pro Pump, Instructions, English — View PDF
  • 3A9514A, Python XL Chemical Injection Pump, Manual, English — View PDF
  • 3A0732U, Manual, Merkur ES Spray Packages, Instructions-Parts, English — View PDF
  • 312796S, NXT Air Motor, Instructions and Parts, English — View PDF
  • 3A5505F, Manual, Python XL-DA, Instructions, English — View PDF
  • 3A5938F, Manual, Python XL-DA ATEX, Instructions, English — View PDF
  • 3A3442B, NXT Air Motor, Instructions-Parts-Repair Manual, English — View PDF
  • 3A3948K, Manual, Python Chemical Injection Pump, Instructions, English — View PDF
  • 3A4019K, Manual, Python XL Chemical Injection Pump, English — View PDF
  • 333015EN-P, Manual, Endura-Flo™ 3D150, 3D350, 4D150, and 4D350 Diaphragm Pump, Instructions, Parts, English — View PDF
  • X018169B, NXT® Air Motor, Instruction Manual, English (US) — View PDF
  • 3A4938P, Manual, InvisPac HM25c Hot melt Delivery System, Instructions -Parts English (US) — View PDF

Kit 24A537 includes the parts for the Air Valve Repair Kit as listed in the reference table: Ref 1 (AIR VALVE PISTON, qty 1), Ref 2 (DETENT PISTON, qty 1), Ref 3 (PLATE, air valve, qty 1), Ref 4 (SCREW, M3, thread forming, qty 2), Ref 5 (ROLLER, detent, qty 1), Ref 6 (SPRING, detent, qty 1), Ref 7 (CUP, for Kit 24A537, qty 1), Ref 8 (PIN, detent, qty 1), Ref 9 (CAM, detent, qty 1), Ref 10 (O-RING, qty 2), Ref 11 (U-CUP, qty 2), Ref 12 (O-RING for models compatible with DataTrak with Runaway Protection, qty 1), and Ref 13 (AIR VALVE GASKET, qty 1).

Sign-up to get 5% off your first order
Click for recommended parts and accessories


Feel free to call or chat with us for recommendations.

📦 Ships in 2-3 weeks, shipping times may vary
🚚 Free Shipping on orders $500 and up., some items have a optional lift gate for a additional fee
Flat rate of $12.50 for orders below $500.
Click here for more info.
🔁 30-day returns. Click here for more info.

The Graco 24A537 Small Air Valve Mech Kit contains the air valve piston, detent piston, air valve plate, two M3 thread-forming screws, detent roller, detent spring, cup, detent pin, detent cam, two O-rings, two U-cups, one O-ring for DataTrak models with Runaway Protection, and an air valve gasket (Ref. 1–13 in the parts diagram). This kit provides the parts listed for the Air Valve Repair Kit in the Graco parts manual reference table.
