Graco 24B622 Buna-N Standard Diaphragm Kit
Graco 24B622 Buna-N Standard Diaphragm Kit

Graco 24B622 Buna-N Standard Diaphragm Kit

$238.00
$238.00
Quantity must be 1 or more

Related Manuals:

  • 406807D - Bolt-Through Diaphragm Kits, Instructions, English — View PDF
  • 334390E, Husky™ 1050HP 2:1Air-Operated Diaphragm Pump, Repair/Parts, English — View PDF
  • 334189S, Husky™ 1050e Electric Diaphragm Pump, Repair/Parts, English — View PDF
  • 313435ZAS, Manual, 1050 Air-Operated Diaphragm Pump, Repair/Parts, English — View PDF

Kit 24B622 (Buna-N) includes reference 101 (DIAPHRAGM, 2 qty), reference 103 (O-RING, shaft bolt, 2 qty), reference 104 (TOOL, diaphragm install, 1 qty), reference 105 (O-RINGS, manifold, PTFE, 8 qty; ADHESIVE, anaerobic, 1 qty; SEAT, 4 qty), and BALLs (4 qty).

Sign-up to get 5% off your first order
Click for recommended parts and accessories


Feel free to call or chat with us for recommendations.

📦 Ships in 6-10 days, shipping times may vary
🚚 Free Shipping on orders $500 and up., some items have a optional lift gate for a additional fee
Flat rate of $12.50 for orders below $500.
Click here for more info.
🔁 30-day returns. Click here for more info.

Restore your sprayer with the Graco 24B622 Buna-N Standard Diaphragm Kit, which includes the diaphragm (Ref. 101), shaft bolt O-ring (Ref. 103), diaphragm install tool (Ref. 104), and manifold O-rings, adhesive, seats, and balls (Ref. 105) from the exploded parts diagram. This genuine Graco kit provides everything listed above for a complete diaphragm replacement.
