Graco Modu-Flo® AL-50 Pneumatic Pump without Reservoir

Graco Modu-Flo® AL-50 Pneumatic Pump without Reservoir

Regular price
$1,340.00
Sale price
$1,340.00
Quantity must be 1 or more


Mix and match pumps, reservoir and manifolds in any configuration to meet any application. Replace the pump or reservoir without disconnecting lubrication lines.

  • Easy to standardize on components and reduce inventory
  • Adjustable pump output for fast, convenient customizing
  • Lubriquip part number 521-000-041
UPC Product: 00633955351134
Family Code: FAMMPM
Unit of Measure: EA
Height: 6 IN   |  15.24 CM
Length: 16.8 IN   |  42.672 CM
Width: 6 IN   |  15.24 CM
Volume: .35 FT3   |  .01 M3
Chargeable Weight: 7.5 LBS  | 3.4 KG

Technical Specifications

Type Pneumatic Piston Pump
Application In-Plant Machinery
Compatible Material Oil, Grease
Maximum Air Inlet Pressure (bar) 10.34
Maximum Air Inlet Pressure (kPa) 1034
Maximum Air Inlet Pressure (psi) 150
Maximum Cycle Rate (CPM) 30
Maximum Fluid Output Pressure (psi) 3500
Maximum NLGI Grade #2
Maximum Working Pressure (bar) 207
Maximum Working Pressure (kPa) 20680
Maximum Working Pressure (psi) 3000
Model Modu-Flo
Power Type Pneumatic
Series AL-50
Compatible Metering Device Series Progressive
Overall Depth (cm) 8.1
Overall Depth (in) 3.188
Overall Depth (mm) 81
Overall Height (cm) 8.1
Overall Height (in) 3.188
Overall Height (mm) 81
Overall Width (cm) 32.5
Overall Width (in) 12.812
Overall Width (mm) 325
Maximum Working Pressure (MPa) 31
maximum_fluid_output_pressure_bar 241
