High Pressure Pneumatic Fluid Regulator, 5000 psi (360 bar) max fluid inlet pressure, 70-900 psi (5-60 bar) regulated pressure range

High Pressure Pneumatic Fluid Regulator, 5000 psi (360 bar) max fluid inlet pressure, 70-900 psi (5-60 bar) regulated pressure range

Regular price
$2,715.58
Sale price
$2,715.58
Quantity must be 1 or more


For use in air-assisted spray systems to ensure accurate, positive control of fluid pressure to a spray gun, dispensing valve, or atomizing head.

UPC Product: 00633955801769
Family Code: FAMCNV
Unit of Measure: EA
Height: 6.4 IN   |  16.256 CM
Length: 13.9 IN   |  35.306 CM
Width: 9.5 IN   |  24.13 CM
Volume: .489 FT3   |  .014 M3
Chargeable Weight: 9.72 LBS  | 4.41 KG

Technical Specifications

Actuation Type Air
Gauge Port Size (cm) 0.635
Gauge Port Size (in) 1/4
Gauge Port Size (mm) 6.35
Gauge Port Type BSPP
Includes Gauge, Medidor
Inlet Size (cm) 1.905
Inlet Size (in) 3/4
Inlet Size (mm) 19.05
Inlet Thread Type BSPP
Maximum Flow Rate (GPM) 11.3
Maximum Flow Rate (L/min) 42.8
Maximum Operating Temperature (°C) 80
Maximum Operating Temperature (°F) 176
Maximum Regulated Pressure (bar) 62
Maximum Regulated Pressure (kPa) 6200
Maximum Regulated Pressure (psi) 900
Maximum Working Pressure (bar) 360
Maximum Working Pressure (kPa) 36000
Maximum Working Pressure (psi) 5000
Minimum Operating Temperature (°C) 10
Minimum Operating Temperature (°F) 50
Minimum Regulated Pressure (bar) 5
Minimum Regulated Pressure (kPa) 500
Minimum Regulated Pressure (psi) 70
Outlet Size (cm) 1.905
Outlet Size (in) 3/4
Outlet Size (mm) 19.05
Outlet Thread Type BSPP
Wetted Material Stainless Steel, Carbide
Gauge Port Thread Gender Female
Type Fluid Regulator
Maximum Fluid Pressure (bar) 345
Maximum Fluid Pressure (kPa) 34450
Maximum Fluid Pressure (psi) 5000
Maximum Fluid Pressure (MPa) 34.5
Inlet Thread Gender Female
Outlet Thread Gender Female
Maximum Regulated Pressure (MPa) 6
Maximum Working Pressure (MPa) 36
Minimum Regulated Pressure (MPa) 0.5

;
