The BARWALT® Pre-Pitch™ System is a unique, stay-in-place screeding tool designed for use underneath shower pan liners. Pre-Pitch™ creates the proper sub floor pitch (1/4" per 12" run) needed to direct water flow towards the weep holes, so it doesn't get trapped and create mold and mildew related issues. The plastic Pre-Pitch™ sticks have holes in their vertical web which helps to act as reinforcement and are easily cut with a hacksaw, PVC cutter, or dry diamond blade. For wood subfloors, Pre-Pitch™ can be screwed or nailed in place. For concrete subfloors, use two-sided tape. Subfloor must be level, sound, and properly prepared prior to installing Pre-Pitch™. For standard shower areas with a center drain or smaller custom shower areas, use the Pre-Pitch™ Standard Kit. Use the Pre-Pitch™ Extended Kit for larger custom shower areas. These products are Made in the USA with Global Materials.
- Used to create the sub floor pitch to direct water to weep holes
- Easily cut with hacksaw, PVC cutter, or dry diamond blade
- For "goof proof" subfloor construction
- Pre-Pitch™ Standard Kit for use with standard shower areas and custom shower areas where the drain is within 36" (914 mm) of each wall; tapered sticks measure 1/8" to 7/8" (3 mm to 22 mm) and are 36" long; 6 per pack, screws and tape included
- Pre-Pitch™ Extended Kit for use with custom shower areas where the walls are more than 36" (914 mm) but less than 72" (1829 mm) from the drain; tapered sticks measure 7/8" to 1-5/8" (22 mm to 41 mm) and are 36" long (914 mm); 4 per pack, screws and tape included
- Made in the USA with Global Materials
