RANSBURG A11241-01 MANIFOLD,VALVE,ASSY,SINGLE,PURGE,EVOLVER-303
| Item # | Part# - Description | Qty |
| 1 |
A11213-00 Valve, Manifold, RMA-303 | 1 |
| 2 | 77367-00 Seat, Valve | 2** |
| 3 | 78949-00 Assembly, Valve | 2* |
| 4 | 79001-38 O-Ring, Solvent Proof | 3 |
| 5 | 77620-00 Kit, Valve Plug | 1 |
*Install assemblies as shown. Apply A11545-00 petroleum jelly to o-rings. Torque to 15-20 lbs•in (1.70-2.3 Nm) after valve is down.
**Install valve seat assemblies as shown. Apply A11545-00 petroleum jelly to o-rings. Torque to 15-20 lbs•in (1.70-2.3 Nm)
