Spraying Systems Co. 1/8GG-SS8W FullJet® Nozzle, 303 Stainless Steel

Spraying Systems Co. 1/8GG-SS8W FullJet® Nozzle, 303 Stainless Steel

Regular price
$115.16
Sale price
$115.16
Quantity must be 1 or more


Feel free to call or chat with us for recommendations.

📦 Shipping times may vary contact us for more information
🚚 Free Shipping on orders $500 and up., some items have a optional lift gate for a additional fee
Flat rate of $12.50 for orders below $500.
Click here for more info.
🔁 30-day returns. Click here for more info.

Description

  • Solid cone-shaped spray pattern with round impact area
  • Unique vane design minimizes turbulence of the fluid to ensure uniform spray distribution and consistent spray coverage
  • Large unobstructed flow passages minimize clogging and increase throughput
  • Removable caps and vanes in most models make maintenance fast and easy
  • Standard, wide and narrow spray angles

Flow

The liquid enters the nozzle and proceeds through the vane. The vane causes the liquid to swirl. The design of the nozzle ensures the liquid continues to swirl as it enters the orifice. The liquid breaks up as it exits the nozzle orifice forming a well defined cone pattern. The drops are uniform in size and distributed equally throughout the spray pattern.



Specification:

Product Type Nozzle
Inlet Connection Gender Male
Inlet Connection Size 1/8 in
Inlet Connection Thread Type NPT
Inlet Connection Type Threaded (Male NPT)
Liquid Flow Rate Range 0.68 - 2.1 gpm
Liquid Pressure Range 7 - 80 psi
Material Composition 303 Stainless Steel
Relative Drop Size Range 500 - 5,000 µm
Spray Pattern Full Cone
