| Technical Specifications | |
| Item: | Spring Return Hose Reel |
| Reel Inlet: | 1/4" (F)NPT |
| Hose Outlet: | 1/4" (M)NPT |
| Bearings: | Permanently Lubricated |
| Max. Temp.: | 150 Degrees F |
| Overall Height: | 18-5/8" |
| Housing Material: | Steel |
| Latch: | Locking |
| Enclosed Reel: | No |
| Includes: | Low Pressure Aluminum Performance Hose Reel - Spring Rewind Hose Reel - Low Pressure Hose Reel - Retractable Hose Reel - Air Compressor Reel - Aluminum Hose Reel |
| Overall Width: | 6-3/4" |
| Hose Material: | No |
| Mounting: | Floor, Wall, Ceiling and Vehicles |
| Overall Length: | 17-1/8" |
| Media - Hose Reels: | Air, Water |
| Drive Type - Hose Reels: | Spring Return |
| Hose Length: | 30 ft. |
| Max. Pressure: | 300 psi |
| Duty Rating: | Heavy Duty |
| Hose Included: | No |
| Swivel Material: | Brass |
| Hose Inside Dia.: | 1/2" |
| Seal Type: | Nitrile |
| Finish - Hose Reels: | Powder Coated |
| Application: | Nitrogen Dispensing, Tire Services, Automotive Dealerships, Automotive & Fleet Service Centers, Service / Mechanic Trucks, Air/Water Services, Pneumatic Tools, Chemical Fluid Transfer, Lightweight Unit Requirements Service / Mechanic Trucks |
Feel free to call or chat with us for recommendations.
📦
Ships in 2-3 weeks, shipping times may vary
🚚
Free Shipping on orders $500 and up., some items have a optional lift gate for a additional fee
Flat rate of $12.50 for orders below $500.
Click here for more info.
Flat rate of $12.50 for orders below $500.
Click here for more info.
🔁
30-day returns. Click here for more info.
COXREELS® Alumi-Pro® "Aluminium Professional-Grade" spring driven hose reels have the strength of steel without the weight! The Alumi-Pro® series is modeled after Coxreels' popular P Series line of hose reels, but are uniquely constructed out of high-quality aluminum. They're compact, lightweight, and non-corrosive making them the perfect choice when polypropylene or plastic hose reels are not the preferred choices due to their limited strength and durability.\
APPLICATION:
Built for Nitrogen Dispensing, Tire Services, Automotive Dealerships, Automotive & Fleet Service Centers.
SWIVEL
- External fluid path with machined solid brass 90° full-flow NPT swivel inlet
- Swivel Seals: NITRILE
DESIGN & STRUCTURE
- Single pedestal reel for applications that require professional grade strength without the weight
- Guide arm adjusts to wall, floor, vehicle & overhead positions
RETRACT
- Spring Rewind
SIGNATURE FEATURES:
- Professional grade heavy duty steel construction
- Rolled edges & ribbed discs provide strength & safety
- Leading 2-year manufacturer's limited warranty
- Made in the U.S.A. - Sold & Supported Worldwide
- SWIVEL - Machined from solid brass 90◦ full-flow NPT swivel for simple seal maintenance and fast and easy hose installation. No need to remove the reel from its mount.
- CARTRIDGE MOTOR - Lubricated and enclosed cartridge-style motor is easily removable for safe and convenient maintenance. Precision coil spring factory tuned and matched to the application for longest life cycle and performance.
- CNC SPUN DISCS - Heavy duty CNC robotically spun and ribbed discs with rolled edges for greater strength, durability, hose protection, and operator safety.
- 1/4" ALUMINUM BASE - Sturdy single pedestal design with solid one-piece aluminum base and support post, no weld, for maximum stability and professional grade strength without the weight.
- MULTI-POSITION GUIDE ARM - Versatile aluminum guide arm adjusts to wall, floor, ceiling, and vehicle mounting positions.
- OTHER FEATURES INCLUDE - long lasting, chip resistant and rust inhibiting CPC powder coat finish, adjustable solid rubber hose stop, and sturdy permanently lubricated precision bearings.
