Trabon® Replacement Rupture Indicator, 1/8-27 NPSF with O-Ring, 3700 psi (255 bar)

Trabon® Replacement Rupture Indicator, 1/8-27 NPSF with O-Ring, 3700 psi (255 bar)

Regular price
$65.72
Sale price
$65.72
Quantity must be 1 or more


Used on MH divider valve applications where lube system pressures exceed 2,500 psi (172 bar).

  • High pressure from blockage causes a disc to rupture
  • Lubricant forces an indicator pin to protrude, indicating the blockage
  • High pressure backs up through the system and trips a switch to shut the system off
  • When fault is corrected, disc must be replaced and pin reset
  • Lubriquip part number 509-499-105
UPC Product: 00633955331495
Family Code: FAMCPT
Unit of Measure: EA
Height: 1.55 IN   |  3.937 CM
Length: .55 IN   |  1.397 CM
Width: .45 IN   |  1.143 CM
Volume: 0 FT3   |  0 M3
Chargeable Weight: .09 LBS  | .04 KG

Technical Specifications

Application In-Plant Machinery, Compressor Equipment
Compatible Material Oil
Connection Size (in) 0.125
Indicator Type Rupture Indicator
Maximum Working Pressure (bar) 255
Maximum Working Pressure (kPa) 25500
Maximum Working Pressure (psi) 3700
Overall Width (mm) 14.224
Overall Length (cm) 4
Overall Length (in) 1.77
Overall Length (mm) 45
Overall Width (cm) 1.4224
Overall Width (in) 0.56
Thread Type NPSF
Type Relief Indicator
Maximum Working Pressure (MPa) 26
Model Trabon

;
