Trabon® Replacement Rupture Indicator, 1/8-27 NPTF, 4600 psi (317 bar)

Trabon® Replacement Rupture Indicator, 1/8-27 NPTF, 4600 psi (317 bar)

Regular price
$143.51
Sale price
$143.51
Quantity must be 1 or more


Trabon Performance Indicators are pressure-sensitive devices that pinpoint excessive pressure in Trabon series progressive lubricating systems. These devices, which are installed in the alternate outlet ports of divider valves, signal a fault either by causing an indicator pin to protrude or by releasing lubricant to the atmosphere. All Performance Indicators respond quickly to protect the lube system and locate lube line blockage.

Used on MH divider valve applications where lube system pressures exceed 2,500 psi (172 bar).

  • High pressure from blockage causes a disc to rupture.
  • Lubricant forces an indicator pin to protrude, indicating the blockage.
  • High pressure backs up through the system and trips a switch to shut the system off.
  • When fault is corrected, disc must be replaced and pin reset.
  • Divider Valve Rupture Indicators w/Memory - 4,600 psi
  • Lubriquip part number 509-499-120
  • Trabon part number 9499-12
UPC Product: 00633955337145
Family Code: FAMCPT
Unit of Measure: EA
Height: .6 IN   |  1.524 CM
Length: 1.55 IN   |  3.937 CM
Width: .6 IN   |  1.524 CM
Volume: 0 FT3   |  0 M3
Chargeable Weight: .09 LBS  | .04 KG

Technical Specifications

Application In-Plant Machinery, Compressor Equipment
Compatible Material Oil
Connection Size (in) 0.125
Indicator Type Rupture Indicator
Maximum Working Pressure (bar) 317
Maximum Working Pressure (kPa) 31700
Maximum Working Pressure (psi) 4600
Overall Width (mm) 14.224
Overall Length (cm) 4
Overall Length (in) 1.77
Overall Length (mm) 45
Overall Width (cm) 1.4224
Overall Width (in) 0.56
Thread Type NPTF
Type Relief Indicator
Maximum Working Pressure (MPa) 32
Model Trabon

;
