UPC Product: 00633955220867
Family Code: FAMAPA
Unit of Measure: EA
Height:
7.5 IN
| 19.05 CM
Length:
2.6 IN
| 6.604 CM
Width:
3.65 IN
| 9.271 CM
Volume:
.041 FT3
| .001 M3
Chargeable Weight:
1.69 LBS
| .77 KG
Technical Specifications
| Air Inlet Size (cm) | 0.3175 |
|---|---|
| Air Inlet Size (in) | 1/8 |
| Air Inlet Size (mm) | 3.175 |
| Air Inlet Thread Gender | Female |
| Air Inlet Thread Type | NPT |
| Compatible Material | Sealants, Adhesives |
| Fluid Inlet Size (cm) | 0.635 |
| Fluid Inlet Size (in) | 1/4 |
| Fluid Inlet Size (mm) | 6.35 |
| Fluid Inlet Thread Gender | Female |
| Fluid Inlet Thread Type | NPT |
| Fluid Outlet Size (cm) | 0.635 |
| Fluid Outlet Size (in) | 1/8 |
| Fluid Outlet Size (mm) | 6.35 |
| Fluid Outlet Thread Gender | Female |
| Fluid Outlet Thread Type | NPT |
| Maximum Shot Cycle Rate (shots/min) | 15 |
| Maximum Shot Size (cc) | 4 |
| Maximum Viscosity (cP) | 1000000 |
| Maximum Working Pressure (bar) | 220 |
| Maximum Working Pressure (kPa) | 22000 |
| Maximum Working Pressure (psi) | 3200 |
| Minimum Shot Size (cc) | 0.2 |
| Minimum Viscosity (cP) | 3000 |
| Mount Hole Size (in) | 7/16-20 |
| Mount Hole Thread Gender | Female |
| Mount Hole Thread Type | UNF |
| Maximum Working Pressure (MPa) | 22 |
