Automatic Metering Valves- With double acting air cylinder, 7/16–20 unf mounting hole, 1/4 npt(f) material inlet and 1/4 npt(f) material outlet

Automatic Metering Valves- With double acting air cylinder, 7/16–20 unf mounting hole, 1/4 npt(f) material inlet and 1/4 npt(f) material outlet

Regular price
$1,560.00
Sale price
$1,560.00
Quantity must be 1 or more


Used to provide precise dispense of medium– to high–viscosity sealants and adhesives in a non–hazardous location.

UPC Product: 00633955600256
Family Code: FAMAPA
Unit of Measure: EA
Height: 3.56 IN   |  9.042 CM
Length: 7.5 IN   |  19.05 CM
Width: 2.5 IN   |  6.35 CM
Volume: .039 FT3   |  .001 M3
Chargeable Weight: 2.97 LBS  | 1.35 KG

Technical Specifications

Air Inlet Size (cm) 0.3175
Air Inlet Size (in) 1/8
Air Inlet Size (mm) 3.175
Air Inlet Thread Gender Female
Air Inlet Thread Type NPT
Compatible Material Urethanes, Epoxies, Silicone
Fluid Inlet Size (cm) 0.635
Fluid Inlet Size (in) 1/4
Fluid Inlet Size (mm) 6.35
Fluid Inlet Thread Gender Female
Fluid Inlet Thread Type NPT
Fluid Outlet Size (cm) 0.635
Fluid Outlet Size (in) 1/4
Fluid Outlet Size (mm) 6.35
Fluid Outlet Thread Gender Female
Fluid Outlet Thread Type NPT
Maximum Shot Cycle Rate (shots/min) 15
Maximum Shot Size (cc) 4
Maximum Viscosity (cP) 1000000
Maximum Working Pressure (bar) 220
Maximum Working Pressure (kPa) 22000
Maximum Working Pressure (psi) 3200
Minimum Shot Size (cc) 0.2
Minimum Viscosity (cP) 3000
Type Metering Valve
Maximum Working Pressure (MPa) 22

;
