The Baileigh WBS-37VH is the 460V/3-phase version of Baileigh’s vacuum wide belt sander, built for higher-voltage shops that need to finish small or lightweight parts by machine. A 5 HP vacuum conveyor holds workpieces down to 2" x 2" , eliminating the need for manual polishing benches on small-part runs. The 10 HP main motor and 1720 RPM belt drive produce up to 2,700 FPM of abrasive belt speed, and the variable 2–26 FPM conveyor handles thickness from 1/64" to 6" across mild steel, stainless steel, non-ferrous metals, and plastics. Auto sanding height adjustment, a digital readout, and 10 programmable presets simplify changeovers, while auto belt tracking keeps the abrasive centered. UL 987-certified safety systems and a 1-year parts warranty plus Baileigh Lifetime Technical Support complete the machine. Industries & Who It's For Precision Machining Typical work: Machine-finishing small, close-tolerance components in 460V facilities. What they need: Needs accurate dimensional control and a repeatable finish on small parts. Industries: Aerospace, Medical Devices, Electronics, Automotive, Defense Fabrication Typical work: Removing slag and prepping small-to-mid-size parts for paint or coating. What they need: Needs throughput and labor reduction without sacrificing small-part capability. Industries: Construction, Agriculture, Appliance Mfg, HVAC MRO Typical work: Finishing small refurbished components and hardware. What they need: Needs durability, reliability, and quick changeover between jobs. Industries: Marine, Oil & Gas, Power Generation, Rail Common Applications • Small-part precision grinding: vacuum hold-down keeps compact parts secure through tight-tolerance finishing. • Deburring small components: ideal for parts cut on plasma, laser, or waterjet tables that are too small for a standard WBS table. • 460V facilities: brings small-part vacuum sanding capability to higher-voltage shop electrical service. Works with: Mild Steel, Stainless Steel, Non-Ferrous Metals, Plastics Warranty & Support: 1-year parts warranty plus Baileigh Lifetime Technical Support
Features
- 460V/3-phase conveyor motor suits higher-voltage shop electrical service
- 5 HP vacuum hold-down system enables a class-leading 2" x 2" minimum part size
- Vacuum conveyor holds down small or lightweight parts that would otherwise need manual polishing
- 10 HP main motor and 37" x 60" belt match the finishing power of Baileigh’s standard WBS-37H
- Handles material from 1/64" to 6" thick for finer-tolerance finishing work
- Auto sanding height adjustment with 10 programmable presets speeds repeat setups
- Auto belt tracking keeps the abrasive centered, reducing uneven wear and downtime
- UL 987-certified door interlocks, E-stop, and quick-stop abrasive belt e-brake protect operators
- 1-year parts warranty plus Baileigh Lifetime Technical Support for long-term uptime
| Specifications | |
|---|---|
| Abrasive Type | Belt |
| Assembled Dimensions | 65.9" x 52.4" x 73.8" |
| Belt Size | 37 in. x 60 in. |
| Belt Speed | 1720 FPM |
| Conveyor Gear Box Ratio | 1/100 |
| Conveyor Motor (HP) | 1/4 hp |
| Conveyor Speed | 2 - 16 FPM Variable Speed |
| Country of Origin | Taiwan |
| Dust Port Outside Diameter | 5 in. |
| Horse Power | 10 |
| Infeed Table Length | 19.3 in. |
| Maximum Material Width | 37 in. |
| Minimum Material Length | 8" |
| Minimum Material Thickness | 1/64" |
| Model Number | WBS-37VH |
| Motor Amps | 25 |
| Number of Belt Speeds | 1 |
| Warranty | 1 Year |
| Motor HP | 10 |
| Motor Phase | Three |
| Motor Voltage | 460 |
