UPC Product:
755652817161
Family Code:
FAMTEX
Country of Origin:
US
Unit of Measure:
EA
Height:
40.5 IN
| 102.870 CM
Length:
37 IN
| 93.980 CM
Width:
27.5 IN
| 69.850 CM
Volume:
23.848 FT3
| 0.675 M3
Shipping Weight:
210 LBS
| 95.254 KG
Technical Specifications
| Compatible Material | Stains, Oil, Lacquer, Primers, Fillers, Acrylics, Interior Emulsions, Exterior Emulsions, Latex, Plaster, Anti-Corrosive Paints, Fire-Retardant Paint, Intumescent |
|---|---|
| Compatible Replacement Pump | 17H835 |
| Convertible | Non-Convertible |
| Engine Brand | Honda |
| Engine Size (HP) | 6.5 |
| Features | Endurance Vortex MaxLife Pump, SmartControl 3.0, QuikReel, Honda Engine, Advantage Drive, ProConnect 2, Easy Out Filter, Crushproof Inlet Strainer, Heavy-Duty Prime Valve, WatchDog, LED Display, Contractor PC Gun |
| Fluid Inlet Size (in) | 1-5/16 |
| Fluid Inlet Size (mm) | 33.34 |
| Fluid Inlet Thread Type | UN-2A |
| Fluid Outlet Size (in) | 3/8 |
| Fluid Outlet Size (mm) | 9.525 |
| Fluid Outlet Thread Type | NPSM |
| Frame Configuration | Hi-Boy |
| Hose Inlet Diameter (cm) | 0.635 |
| Hose Inlet Diameter (in) | 1/4 |
| Hose Inlet Diameter (mm) | 6.35 |
| Hose Reel Type | QuikReel |
| Includes | Pistola de textura azul para serviço pesado, Heavy-Duty Blue Texture Gun, Pistola de textura azul para trabajo pesado, Tous les appareils sont livrés prêts à pulvériser : avec un pistolet à enduit 289605 HD Bleu, buses PAA517 + LTX427 + LTX531, support de buse 246215 RAC X™, flexible 240797 BlueMax™ II (3/8 po. x 15 m), flexible souple 277249 BlueMax™ II (1/4 po. x 0,9 m), 238049 TSL™ (118 ml)., Todos los equipos se envían completos y listos para pulverizar: con pistola de texturados 289605 HD Blue, boquillas PAA517 + LTX427 + LTX531, protección 246215 RAC X™, manguera 240797 BlueMax™ II (3/8 in x 15 m), manguera flexible 277249 BlueMax™ II (1/4 in x 0,9 m), 238049 TSL™ (118 ml)., Heavy-Duty Blue 텍스처 건, Alle Geräte werden komplett und spritzbereit ausgeliefert: mit 289605 HD Blue Verputzpistole, PAA517 + LTX427 + LTX531 Düse, 246215 RAC X™ Schutz, 240797 BlueMax™ II Schlauch (3/8" x 15m), 277249 BlueMax™ II Peitschenende (1/4" x 0,9m), 238049 TSL™ (118 ml)., Alle toestellen worden compleet en spuitklaar geleverd: met 289605 HD Blue-textuurpistool, PAA517 + LTX427 + LTX531-spuittip, 246215 RAC X™-tiphouder, 240797 BlueMax™ II-slang (3/8" x 15m), 277249 BlueMax™ II-hulpslang (1/4" x 0,9m), 238049 TSL™ (118 ml)., Tutte le unità sono spedite complete e pronte per la spruzzatura: con pistola texture 289605 HD Blue, ugello PAA517 + LTX427 + LTX531, protezione 246215 RAC X™, Tubo flessibile BlueMax™ II (3/8" x 15m) 240797, flessibile a frusta BlueMax™ II (1/4" x 0,9m) 277249, 238049 TSL™ (118 ml)., 重型 Blue 质感涂料喷枪, ヘビーデューティー・ブルーテクスチャーガン, All units shipped complete and ready to spray: with 289605 HD Blue Texture gun, PAA517 + LTX427 + LTX531 Tip, 246215 RAC X™ Guard, 240797 BlueMax™ II Hose (3/8 in. x 15 m), 277249 BlueMax™ II Whip Hose (1/4 in. x 0.9 m), 238049 TSL™ (118 ml)., Heavy-Duty Blue Texture Gun, Ponta de pulverização RAC X LTX 427, RAC X LTX 427 Spray Tip, boquilla de pulverización RAC X LTX 427, RAC X LTX 427 스프레이 팁, RAC X LTX 427 喷嘴, RAC X LTX 427 スプレーチップ, RAC X LTX 427 Spray Tip, Ponta de pulverização RAC X LTX 531, RAC X LTX 531 Spray Tip, boquilla de pulverización RAC X LTX 531, RAC X LTX 531 스프레이 팁, RAC X LTX 531 喷嘴, RAC X LTX 531 スプレーチップ, RAC X LTX 531 Spray Tip, RAC X Guard, RAC X Guard, protección RAC X, RAC X 가드, RAC X 喷嘴座, RAC X ガード, RAC X Guard, Mangueira sem ar BlueMax II de 3/8 pol. x 50 pés, 3/8 in x 50 ft BlueMax II Airless Hose, manguera sin aire BlueMax II de 3/8 pulg. x 50 pies, 3/8 in x 50 ft BlueMax II 에어리스 호스, 3/8 英寸 x 50 英尺 BlueMax II 无气软管, 3/8 インチ x50ftBlueMaxII エアレスホース, 3/8 in x 50 ft BlueMax II Airless Hose, Mangueira de chicote sem ar BlueMax II de 1/4 pol. x 3 pés, 1/4 in x 3 ft BlueMax II Airless Whip Hose, manguera flexible sin aire BlueMax II de 1/4 pulg. x 3 pies, 1/4 in x 3 ft BlueMax II 에어리스 휩 호스, 1/4 英寸 x 3 英尺 BlueMax II 无气快接软管, 1/4 インチ x3ftBlueMaxII エアレス手元ホース, 1/4 in x 3 ft BlueMax II Airless Whip Hose |
| Inlet Paint Strainer | 8 Mesh Stainless Steel Screen |
| Maximum Flow Rate (GPM) | 2.2 |
| Maximum Flow Rate (L/min) | 8.33 |
| Maximum Hose Length (ft) | 200 |
| Maximum Hose Length (m) | 60 |
| Maximum Sound Pressure Level (dB(A)) | 96 |
| Maximum Tip Size (in) | 0.048 |
| Maximum Tip Size Gun 1 (in) | 0.048 |
| Maximum Working Pressure (psi) | 3300 |
| Maximum Working Pressure (kPa) | 22700 |
| Power Rating (HP) | 6.5 |
| Power Source | Gas |
| Power Rating (kW) | 4.85 |
| Power Rating (W) | 4847 |
| Maximum Working Pressure (MPa) | 22.8 |
| Pressure Control Type | SmartControl 3.0 |
| Overall Width (mm) | 620 |
| Model | GMAX II HD |
| Maximum Working Pressure (bar) | 227 |
| Overall Height (cm) | 96.5 |
| Overall Height (in) | 38 |
| Weight (kg) | 76 |
| Weight (lb) | 167 |
| Overall Height (mm) | 965 |
| Overall Length (cm) | 84.6 |
| Overall Width (in) | 24.4 |
| Overall Length (in) | 33.3 |
| Series | 7900 |
| Overall Length (mm) | 846 |
| Overall Width (cm) | 62 |
| Pump Type | Endurance Vortex |
| Type | Airless Sprayer |
| Spray Gun Type | HD Blue Texture Gun |
| Spray Type | Airless |
| Maximum Working Pressure (kg/cm²) | 22.7 |
| Wetted Material | Acetal, Aluminum, Chrome Plating, Fluoroelastomer, Leather, Nylon, PTFE, Polyurethane, Stainless Steel, Tungsten Carbide, UHMWPE, Zinc-Plated Carbon Steel, Nickel-Plated Carbon Steel |
| Maximum Fluid Working Pressure (psi) | 3300 |
| Fluid Hose Inside Diameter (in) | 1/4 |
| Outlet Paint Filter | 60 Mesh Stainless Steel Screen |
| Pump Sleeve Material | MaxLife |
| Pump Mount Type | ProConnect 2 |
| Pump Rod Type | MaxLife |
| Number of Guns | 1 |
| Filter Mesh Size | 60 |
| Maximum Tip Size Gun 2 (in) | 0.035 |
| Recommended Annual Usage | Up to 1,000 gallons per week |
| Maximum Tip Size Gun 3 (in) | 0.027 |
| Maximum Tip Size Gun 4 (in) | 0.023 |
| Power Rating (cc) | 200 |
| Product Series | ProContractor |
