Graco Complete Seal Kit, L200SM (Part Number 255512). Includes seals, wipers, spacers, piston guide bearing, o-ring packing, packing glands, vee packing, and piston/valve seals for Check-Mate 200 pump service.
Features
- Seal, CM200 Wetcup Cover (Qty. 1)
- Wiper, CM200 Wetcup Cover (Qty. 1)
- Spacer, U-Cup, CM200 - CM250 (Qty. 1)
- Bearing, Piston Guide CM200 (Qty. 1)
- Packing, O-Ring (Qty. 1)
- Gland, Packing Female (Qty. 1)
- Gland, Packing Male (Qty. 1)
- Packing, Vee (Qty. 2)
- Seal (8, 10 CM) (Qty. 1)
- Seal, Valve (Qty. 1)
- Seal, Piston (Qty. 1)
- Spacer, U-Cup Bearing, CM200 (Qty. 1)
Specifications
| Part Number | 255512 |
| Type | Complete Seal Kit |
| Compatible System | Check-Mate 200 (L200SM) |
