CE Approved and Certified. Meets or exceeds the standards prescribed by European Standard EN-1493
Multi-caster slip plates
Spring-loaded automatic safety locks
Supersized 12" diameter cable sheaves
Four stainless steel lifting cables
Grease nipples on every sheave and axle
Single hydraulic under-runway cylinder
Integrated hydraulic flow restrictor
Durable powder coat finish
Push-button pneumatic lock release
Secondary lock system on constant guard
Enclosed cables, airlines, safety latches
Multiple adjustable locking positions
Maintenance-free power system
Conveniently located controls
12" x 12" base plates
Runways feature a durable matte finish
Optional rolling jacks available
Capacity
Lifting Capacity*
18,000 lbs. (8,165 kg)
*Max Capacity / Front Axle
9,000 lbs. (4,082 kg)
*Max Capacity / Rear Axle
9,000 lbs. (4,082 kg)
Rise
A - Min. Runway Height:
11.5" (292 mm)
B - Max. Rise:
60" (1,524 mm)
C - Max. Lifting Height:
71.5" (1,816 mm)
Time to Full Rise:
75 seconds
Outside Dimensions
D - Overall Width:
153.5" (3,899 mm)
E - Outside Length:
257" (6,528 mm)
F - Overall Length:
312.5" (7,938 mm)
G - Height of Columns:
91.25" (2,318 mm)
Inside Dimensions
H - Width Between Columns:
133.5" (3,391 mm)
I - Drive-Thru Clearance:
109" (2,769 mm)
Runways
J - Runway Width:
22" (559 mm)
K - Length of Runways:
257.25" (6,534 mm)
L - Width Between Runways:
40" (1,016 mm) or 45.25" (1,149 mm)
Alignment
M - Min. 4-Wheel Alignment:
83" (2,108 mm)
N - Max. 4-Wheel Alignment:
138" (3,505 mm)
O - Max. 2-Wheel Alignment:
211" (5,359 mm)
Minimum Wheelbase
Rated Capacity:
185" (4,699 mm)
75% Capacity:
160" (4,064 mm)
50% Capacity:
135" (3,429 mm)
25% Capacity:
110" (2,794 mm)
Locking
Locking Positions:
13
Lock Spacing:
4
Power Unit
Motor:
220 VAC / 60 Hz / 1 Ph
Noise:
45 dB
Shipping
Weight:
6,790-lbs. (3,079 kg)
Dimensions:
265'' x 27'' x 44'' (6,731 mm x 686 mm x 1118 mm)
Note: An air supply (minimum: 30 psi / 3 CFM) is required for the safety-lock mechanisms to disengage. It is solely the responsibility of the end-user to provide, install and maintain the air supply.
Note: Not all BendPak lift models meet the standards as prescribed by ANSI/ALI ALCTV-2017 or ANSI/UL 201. Consult www.autolift.org for a complete list or contact BendPak via contact@bendpak.com.
BendPak lifts are supplied with concrete fasteners that meet the criteria of the American National Standard ANSI/ALI ALCTV-(Current). Buyer is responsible for all charges relating to any special regional structural or seismic anchoring requirements specified by any other agencies or codes such as the Uniform Building Code (UBC) or International Building Code (IBC).
