Graco QuickShot Sprayer Parts & Accessories

Which Graco Ultra QuickShot do I have? · Versions, model numbers & manuals

Graco has built several versions of the Ultra QuickShot. Find the model or part number on your unit's label and match it to a row below. Parts can differ between versions, so check the manual for your version before ordering.

Version Model / part numbers Graco manual
QuickShot — Service manual 3A9322F
Ultra QuickShot / Ultimate QuickShot 20B473, 826308, 20B476, 20B477, 20B478, 20B479, 20B475 Owner's manual 3A9301 (rev. K)
QuickShot II — Service manual X058396 (rev. B)
Ultra QuickShot II / Ultimate QuickShot II 26E006, 26E007, 26E008, 26E009, 26E010, 26E011, 826319 Operation manual X048114 (rev. C)

Links open the PDF on graco.com. Need help identifying your version? Call (888) 714-1410.

Every replacement part for your Graco QuickShot Cordless Handheld Airless Sprayer, cross-referenced directly to Graco's official parts manual (3A9322EN-D). Pittsburgh Spray Equipment is a full-line Graco distributor — the parts on this page are genuine Graco OEM, not aftermarket.

📘 Graco QuickShot Repair Manual (PDF)

Exploded diagrams, torque specs, service procedures, and complete parts list. Download 3A9322EN-D.pdf →

What's covered

  • Pump assembly + rebuild kits (18H072)
  • Needle valve, solenoid, trigger switch (18H056, 18H057)
  • Bare applicator kit + housing parts (18H059)
  • Cup, lid, and gasket kits (18H078, 18H079)
  • 60-mesh and 100-mesh filters (18H073)
  • Prime knob and prime/spray valve
  • RAC X FFLP fine-finish switch tips
  • OEM DeWalt 20V battery kits (17P557)
  • Fasteners, o-rings, seals, and warning labels

Why buy from Pittsburgh Spray Equipment

  • Same-day shipping on in-stock parts ordered by 2 PM ET
  • Factory-authorized Graco distributor — every part is OEM
  • Free tech support by phone if you're not sure which part you need
  • Repair kit bundles that follow the Graco service procedure

Related Graco parts collections

Not sure which part you need? Call our team at (888) 714-1410 or send the sprayer's model + serial number and we'll look it up against the Graco parts manual for you.
