Powermatic 3520C vs 4224B vs PM2014 — Which Wood Lathe Should You Buy?

Choosing between the Powermatic 3520C, 4224B, and PM2014 comes down to three questions: how big are your projects, how much floor space do you have, and are you turning for work or for love? Get those right and the pick is obvious. This is our year-by-year comparison — pulled from real customer patterns across schools, professional turners, and serious hobbyists ordering these lathes through Pittsburgh Spray Equipment.

If you already know which lathe you want, jump directly to our Powermatic Lathes collection. If you want the parts and accessories that pair with each lathe, we've organized those into a dedicated Powermatic Lathe Parts & Accessories collection.

The 30-second answer

• Powermatic PM2014 — $2,799. 14" swing, 20" between centers, 1 HP variable-speed. Runs on standard 115V household power. The pick for pen turners, small-bowl turners, and anyone tight on shop space or budget who still wants Powermatic build quality.
• Powermatic 3520C — $5,999. 20" swing, 35" between centers, 2 HP variable-speed 230V. The standard-setter for professional turners, teaching schools, and any serious shop. If you don't know which to pick, pick this one — it's the industry reference.
• Powermatic 4224B — $8,799. 24" swing, 42" between centers, 3 HP (1PH or 3PH) 220V, over 900 lb. Heavy-duty flagship — the lathe you buy when the 3520C's 20" swing isn't enough (deep hollow forms, large-diameter bowls, salad-plate stacks, or production runs).

Also worth knowing: the Powermatic PM2020 ($5,939) is essentially a 3520C with a shorter 20" bed. Same 20" swing, same 2 HP motor, same variable-speed controls — but saves you floor space and about $60 if you never turn spindles longer than 20 inches.

Side-by-side specifications

Powermatic PM2014 — the entry point into Powermatic build quality

The PM2014 is Powermatic's benchtop lathe, and it exists to solve a specific problem: hobbyists and small-shop turners who want Powermatic build quality (cast-iron bed, digital readout, electronic braking, variable-speed motor) without the footprint and cost of a 3520C.

Where the PM2014 wins:

• Runs on standard 115V household power — the only Powermatic lathe you can plug into a normal outlet. Every other Powermatic lathe needs 220V.
• Fits on a workbench (or on the matching PM2014 stand at $605 additional).
• 14" swing handles bowls, small vessels, and most pen/spindle work.
• The PM2014 Lathe Light ($198) fits perfectly and doesn't interfere with the tailstock.

Where the PM2014 falls short:

• 20" between centers is short for larger spindle work. If you turn pool cues, table legs, or long balusters, you'll want the 3520C's 35".
• 14" swing limits bowl size — great up to ~13" diameter, tight above.
• 1 HP is enough for hobbyist work but bogs down on large, off-balance turnings.

Pick the PM2014 if: you turn primarily pens, small bowls (under 13"), or spindles under 20" long; you don't have 220V in your shop; you're tight on floor space; or you want to start with Powermatic quality without a $6K spend.

Powermatic 3520C — the industry standard for two decades

The 3520C is the fourth generation of Powermatic's flagship (3520 → 3520A → 3520B → 3520C). If you walk into most professional woodturning schools, high-end craft studios, or dedicated turning shops in North America, this is the lathe you'll see. There's a reason.

The 3520C hits the goldilocks zone: 20" swing + 35" between centers + 2 HP variable-speed handles roughly 90% of what any professional turner needs to do — bowls, hollow forms, spindles, stools, table legs, small furniture parts, and production runs.

What's new for the C model (vs. the older 3520B):

• Brighter digital RPM readout (easier to read from the operator's side of the lathe).
• Improved motor with better low-RPM torque for bowl work.
• Better spindle indexing detent — cleaner engagement, less slop.
• Slight ergonomic refinements to the tailstock quill.

The accessories that pair with the 3520C are extensive: the tailstock swing-away ($440) saves your back on long-project turnovers, the 3520C bed extension ($770) adds another 20" of length, and the outboard turning stand ($880) lets you exceed the 20" swing when you need to. See the full Powermatic Lathe Parts & Accessories collection.

Pick the 3520C if: you're a professional or serious hobbyist turner; you teach; you want the lathe that's standard in the woodturning industry (parts availability, forum knowledge, resale value); or you just want the safe answer.

Powermatic 4224B — heavy-duty for large-diameter and production work

The 4224B exists for turners the 3520C outgrows. That's a smaller audience than you'd think — the 3520C's 20" swing covers most bowl and hollow-form work — but when you need the 4224B, nothing else will do.

What the 4224B offers over the 3520C:

• 24" swing — that extra 4" is a meaningful jump when you're turning deep hollow forms, large-diameter salad platters, or oversized architectural work.
• 42" between centers — 7" longer than the 3520C's 35".
• 3 HP motor — the extra horsepower matters on large off-balance blanks and heavy roughing cuts. It also enables 3-phase electrical for shops with 3PH infrastructure.
• 900+ lb machine weight — the mass dampens vibration on aggressive cuts that would make lighter lathes chatter.

The tradeoffs:

• Heavier and larger footprint — this is not a small-shop machine.
• $8,799 vs $5,999 — an extra $2,800 over the 3520C. Justifiable only if you consistently work at 20"+ diameter or run production shifts.
• 1PH or 3PH 220V required — no household-outlet option.

The 4224B pairs with the 4224B-specific tailstock swing-away ($550) and the same outboard turning stand as the 3520C.

Pick the 4224B if: you consistently turn diameters over 18"; you run production shifts; you're a full-time pro whose income depends on efficiency at the lathe; or you've outgrown a 3520 and know exactly why.

How to decide — a quick flowchart

1. Do you have 220V in your shop? No → PM2014 is your only Powermatic option.
2. Yes 220V. Do you consistently turn diameters over 20"? Yes → 4224B.
3. No, mostly under 20". Do you consistently turn spindles over 30" long? Yes → 3520C (35" bed).
4. No, mostly under 30" spindles too. Want to save $60 and floor space? Yes → PM2020 (same 20" swing, 20" bed).
5. Want the standard industry pick with the widest bed and best resale value? → 3520C.

Powermatic Lathes FAQ (2027)

Is the 3520C worth $2,800 more than the PM2014?
For professional and serious-hobbyist turners: yes, easily. The 3520C's 20" swing (vs. 14"), 2× the horsepower, and 35" between centers unlock projects the PM2014 can't touch. If you're turning purely for hobby and never exceed the PM2014's capacity, the $2,800 stays in your pocket.

Is the 4224B worth $2,800 more than the 3520C?
Only if you regularly turn diameters over 18-20" OR run production shifts. Most turners never exceed the 3520C's capacity, so the extra $2,800 is money spent on capacity you won't use. If you know you need 24" swing (large salad platters, deep hollow forms, architectural work), buy the 4224B; if you don't know, buy the 3520C.

Powermatic PM2020 vs 3520C — which is right?
Same swing (20"), same motor (2 HP), same controls. The PM2020 has a 20" bed vs. the 3520C's 35". If you'll never turn spindles longer than 20", the PM2020 saves $60 and about 15" of floor space. Most bowl turners never need more than 20" of bed; most spindle turners want the extra length.

Is Powermatic still the industry standard vs. Laguna, Robust, and Oneway?
Powermatic's 3520 series has been the woodturning school and pro-shop standard for 20+ years. Robust and Oneway lathes are higher-end options (typically $8K-15K+) with heavier construction, but Powermatic covers 90% of what those premium lathes do at 50-70% of the price with better parts availability. For most turners, Powermatic is still the right answer.

How long is the wait on a Powermatic lathe order?
In-stock 3520C, PM2014, and PM2020 typically ship within 1-2 business days. The 4224B (heavier freight, less-often stocked) can take 5-10 business days depending on current inventory. Order confirmation always includes a firm ship date. Call (888) 714‑1410 for a real-time stock check.

Does Powermatic still make parts for the older 3520A and 3520B?
Yes for most wear items — toolrests, tailstock components, remote switches, and mechanical accessories are still produced and often cross-compatible with newer models. See our Powermatic Lathe Parts & Accessories collection for what's currently stocked. If you can't find a specific 3520A or 3520B part, call us with the Powermatic part number.

Ready to shop?

• 🎯 All Powermatic Lathes
• 🛠️ Powermatic Lathe Parts & Accessories
• 📞 Call (888) 714-1410 to talk to a real technician (not a call center) about which lathe fits your work

Not sure which Powermatic lathe fits your work? Reply to this article or call us — tell us what you turn most (bowls / spindles / pens / production), your longest project, and whether you have 220V. We'll spec the right lathe and any accessories worth adding.
