Collection: Graco LineLazer ES 1000 Parts

Which Graco LineLazer ES 1000 / ES 2000 do I have? · Versions, model numbers & manuals

Graco has built several versions of the LineLazer ES 1000 / ES 2000. Find the model or part number on your unit's label and match it to a row below. Parts can differ between versions, so check the manual for your version before ordering.

Version	Model / part numbers	Graco manual
LineLazer V 3900 / LineLazer V 5900 / LineLazer V 200HS / LineLazer V 200DC	—	Operation manual 3A3428 (rev. B)
LineLazer ES 1000 / LineLazer V ES 2000 / LineDriver ES	25U767, 25U768, 25U672, 25U769	Service manual 3A9032 (rev. A)
LineLazer ES 1000 / LineLazer ES 2000 / ES 2000 (Standard Series) / ES2000 (HP Auto Series)	—	Service manual 3A9033 (rev. A)
LineLazer ES 1000 / LineLazer ES 2000	—	Service manual 3A4746B
UltraMax II and Ultimate MX II 695/795 Displacement Pump Repair	248204, 255968, 248205, 249059, 249057, 277069, 277070, 253056, 257146	Service manual 310643 (rev. W)

Links open the PDF on graco.com. Need help identifying your version? Call (888) 714-1410.

About Graco LineLazer ES 1000 Parts · 232 in stock · Manual · Buying Guide · FAQ

Every replacement part for the Graco LineLazer ES 1000 line striper ships direct from Pittsburgh Spray Equipment . Genuine OEM only. Same-day part identification: call (888) 714-1410, email sales@pittsburghsprayequip.com, or text a photo of your ID plate to (833) 670-5756.

Owner's Manual

LineLazer ES 1000 Owner + Parts Manual

Common Repair Categories · Why Buy from PSE · FAQ

Common Repair Categories

Batteries & chargers — replacement packs, charge cables, dock parts
Pump service — packings, piston rods, seats, rebuild kits
Filters & strainers — inlet strainer, gun filters
Hoses & fittings — airless hose, whip hose, quick-disconnects
Guns & tips — LineLazer guns, HD RAC tips, tip guards
Wheels & drive — front caster, rear wheels, wheel bearings
Seals & gaskets — pressure adjustment, o-rings, packing kits

Use the filter menu above the product grid to narrow by category.

Why Buy Genuine OEM from Pittsburgh Spray Equipment

Genuine OEM parts shipped from Graco
Same-day part ID help — text a photo of your machine's ID plate to (833) 670-5756
Financing available on machines over $1,000
Ships direct from stocked Pittsburgh warehouse

FAQ

What batteries does the ES 1000 use?
The Graco LineLazer ES 1000 runs on a proprietary Graco lithium-ion battery pack. Standard runtime is roughly a full day of typical property-maintenance striping on a single charge. Charge time from empty is a few hours on the included charger.

What are the pros vs cons of the ES 1000 vs a gas striper?
Pros: no fuel, no exhaust, quiet operation (indoor-safe for garages/warehouses), fewer wear items (no engine service). Cons: batteries eventually degrade and need replacement, and cold-weather runtime drops noticeably below 40°F. Best fit is property managers, small contractors, and indoor stripers.

Do LineLazer HD RAC tips fit the ES 1000?
Yes — the ES 1000 accepts the same LineLazer HD RAC tip family as Graco's gas stripers. Since the ES 1000 outputs lower pressure than the gas V-series, stick to smaller tip sizes (.011-.015) for clean line width.

How do I extend the ES 1000 battery life?
Store batteries at partial charge (50-70%), not fully depleted or fully charged, when the machine is out of use. Avoid leaving batteries in a hot truck bed in summer or freezing overnight in winter. Fully cycle the battery every 30-60 days if the machine sits idle.
